Smart Node
A wireless commercial HVAC terminal equipment controller with flexible inputs and outputs for zone-level control across equipment types.
0
75F® Connect Module™
SMART UNIT CONTROLLER & I/O MODULE WITH LOW-CODE DRIVEN PROFILE SEQUENCES
|
Dimensions |
5.5” x 4.13” x 1.22” (140 mm x 105 mm x 31mm) |
|
Mounting |
Wall |
|
Screen |
TFT LCD, 1.77", 128 x 160 Pixels (RGB) |
|
Inputs |
(8) Universal inputs (1) OWI to connect to 75F sensors (1) POR to connect to 75F sensors |
|
Outputs |
(4) 0-10V dc or 4-20mAanalog outputs (8) relays rated at 0.5A at 120V ac or 2A at 24 V ac/dc resistive load |
|
Bluetooth |
Bluetooth 4.1 |
|
Wired |
RS485 port for Modbus RTU or BACnet MSTP communication 75F OWI sensor port PoR - Power over RS485 to enable communication with the HyperLite and other 75F sensors over two standard thermostat wires. |
|
Power |
24V AC/DC(+/-15%) with nominal |
